SP8000UV Double Beam UV-Visible Spectrophotometer

SP8000UV Double Beam UV-Visible Spectrophotometer

Double-Beam Precision for Demanding Research
ISO 13485:2016 Certified FDA Registered Facility
  • Double-Beam
  • Color TFT Touchscreen
$9,975.00
Estimated Delivery:Oct 04 - Oct 08
Guarantee safe & secure checkout

Overview

The SP8000UV is a high-performance double-beam UV-Vis spectrophotometer covering 190–1100 nm with 0.3 nm spectral resolution, designed for laboratories requiring precision and versatility across UV, visible, and near-infrared applications. Its double-beam optical design delivers continuous baseline correction for consistent, reproducible results, while combined tungsten and deuterium lamps provide seamless full-spectrum coverage without manual lamp switching. A 10.1-inch color TFT touchscreen (1280×800) offers intuitive operation and real-time spectral display, and the wide photometric range (-4 to +4 A, 0–400 %T, 0–9999.9 C) accommodates diverse sample types and concentration levels — making the SP8000UV a flexible, CE-certified solution for clinical, research, environmental, and industrial laboratories.

Specifications

Beam Design: Double-beam
Wavelength Range: 190–1,100 nm
Spectral Resolution: 0.3 nm
Bandwidth: 1.0 nm
Light Source: Tungsten + Deuterium
Wavelength display:0.1 nm
Wavelength swing speed:10000 nm/min
Wavelength scanning speed: 20 ~ 4200 nm/min
Photometric range: -4 ~ 4 A，0 ~ 400 %T，0 ~ 9999.9 C
Photometric accuracy: ±0.002 A @ 0.0 ~ 0.5 A，±0.004 A @ 0.5 ~ 1 A，±0.3 %T @ 0 ~ 100 %T
Photometric repeatability: ≤0.001 A @ 0.0 ~ 0.5 A，≤0.002 A @ 0.5 ~ 1 A，≤0.15 %T @ 0 ~ 100 %T
Noise: ≤0.00005 A @ 0.0 A （500 nm，RMS）
Display Type: Color TFT Touchscreen
Display Size: 10.1"
Display Resolution: 1280×800
Photometric Range: -4–4 A, 0–400 %T, 0–9,999.9 C
Certification: CE
Warranty: 1 year

Applications

SP8000UV Double Beam UV-Visible Spectrophotometer

Our UV/Visible Spectrophotometer covers the full range of laboratory needs — from single and multi-wavelength Photometry to Kinetics, Time Scanning, and Spectrum Scanning. Built-in Quantitation enables accurate concentration measurements via standard curves, while the dedicated Biological Method module provides rapid, reliable quantification of DNA, RNA, and proteins. One instrument, every application.

Key Features

Double-Beam Optical Design

Simultaneous measurement through both sample and reference beams ensures real-time baseline correction, delivering superior accuracy, stability, and reproducibility compared to single-beam instruments.

Wide Wavelength Range: 190–1100 nm

Covers the full UV, visible, and near-infrared spectrum in a single instrument, supporting a broad range of analytical applications from nucleic acid quantification to colorimetric assays and material analysis.

High Spectral Resolution: 0.3 nm

Exceptional 0.3 nm resolution enables precise differentiation of closely spaced spectral peaks, making it suitable for demanding quantitative and qualitative analyses requiring fine spectral detail.

1.0 nm Fixed Bandwidth

Consistent 1.0 nm spectral bandwidth delivers narrow, well-defined light beams for accurate absorbance measurements across diverse sample types and concentrations.

Dual Light Source: Tungsten + Deuterium Lamps

Combined tungsten and deuterium lamp system provides seamless, uninterrupted coverage across the full 190–1100 nm wavelength range without manual lamp switching.
